# Underpinning Structural Engineer Toronto: PEng Scope & Selection

Every legal basement underpinning project in Toronto requires a structural design produced and stamped by a Professional Engineer registered with PEO (Professional Engineers Ontario). The engineer's stamp is not optional — the Ontario Building Code, the City of Toronto Building Permit process, and the homeowner's insurer all require it. The engineer is the legally responsible party for the structural design, the underpinning sequence, and the safety of the work.

This article explains what the PEng does on a Toronto underpinning project, how the engineer fits into the broader project team, the scope and fees involved, and how RenoHouse coordinates with the Toronto-area engineering firms we work with regularly. For the full project context, see our [Basement Underpinning Toronto: Complete 2026 Guide](/blog/basement-underpinning-toronto-2026-complete-guide).

Why a PEng Is Required

The Ontario Building Code (OBC) requires that any work involving the structural design of a building be designed by a Professional Engineer or Architect, sealed and signed. Section 1.2 of Division C explicitly applies this requirement to foundation work, including underpinning. The City of Toronto Building Department will not accept an underpinning permit application without engineer-stamped drawings.

There is no DIY path, no draftsperson workaround, no contractor substitute. The PEng stamp is the legal foundation of the project.

The reasons are not bureaucratic. Underpinning involves controlled removal of structural support beneath a load-bearing foundation. Mistakes — wrong pin width, wrong sequence, inadequate shoring, premature cure — can cause settlement, cracking, or in extreme cases partial collapse of the wall above. The engineer's design discipline is what prevents these outcomes.

What the Engineer Actually Designs

For a typical Toronto residential underpinning project, the engineer's deliverables include:

1. Structural drawings (stamped):

• Plan view of the perimeter foundation showing pin numbering and sequence.
• Section details showing the new wall geometry, dowel placement, concrete strength, and the connection to the existing footing above.
• Wall elevation showing pin width, pin depth, and bench detail (where applicable).
• Shoring details where temporary support is required.
• Reinforcement schedule.
• Concrete specification (typically 30 MPa to 35 MPa for underpinning, higher than the standard 20 MPa for residential foundations).

2. Pin sequence schedule:

• Numbered pins around the perimeter.
• Required cure time between adjacent pin excavations (typically 48 to 72 hours).
• Maximum number of pins that can be open simultaneously (typically 1 in 4 around the perimeter).

3. Soil report review and integration:

• The engineer reviews the geotechnical report (or specifies one if not yet completed) and integrates findings into pin width, depth, and shoring specification.
• Sandy soils typically drive narrower pins (2.5 to 3 feet); clay accommodates wider pins (3 to 4 feet); bedrock often allows simplified shoring.

4. Construction notes and specifications:

• Concrete mix and placement requirements.
• Rebar grade and placement.
• Dampproofing or waterproofing requirements at the new wall.
• Backfill and drainage requirements.

5. Site visits during construction:

• Pre-construction site review.
• Mid-project review (typically after first pin sequence is complete).
• Final review before slab pour.
• Sign-off letter for the City confirming construction matches design.

For a multiplex conversion or more complex scope, the engineer may also design:

• New beams above to support unit-separation framing.
• Lintels and headers for new openings (egress windows, separate entrances).
• Temporary needling or shoring for the main floor during work.

The Engineer's Role During Construction

The engineer's responsibility does not end when drawings are stamped. During construction, the engineer:

• Reviews shop drawings if any pre-fabricated steel or prefab elements are involved.
• Issues clarifications and revisions when site conditions reveal something the original drawings did not anticipate (eroded mortar, surprise mid-floor footing, unexpected soil change).
• Conducts site visits at key milestones — first pin pour, mid-project, final.
• Signs the construction commencement and completion letters for the City.
• Reviews concrete delivery tickets if requested for major pours.
• Issues a final letter of compliance confirming the work was completed in accordance with the stamped drawings.

The contractor builds to the drawings. The engineer confirms the drawings were followed. The City inspects. The combination of engineer responsibility, contractor performance, and inspector verification is what makes the system work.

Engineer Fees in 2026 Toronto

Residential underpinning engineering fees in 2026:

• Bench footing only project: $2,000 to $3,500 design plus $600 to $1,200 site visits.
• Standard residential full underpin: $4,500 to $7,500 design plus $1,500 to $2,800 site visits.
• Complex underpin (multiple beams, structural openings, multiplex scope): $6,500 to $12,000 design plus $2,500 to $5,500 site visits.
• Underpin combined with second-storey addition or major above-grade work: $8,500 to $18,000 combined structural fee.

Fees are paid by the homeowner directly to the engineer or through the contractor's invoice — payment structure varies. We typically include engineer fees as a line item in the project budget rather than burying them in the contractor markup.

The Toronto-Area Engineering Firms We Coordinate With

RenoHouse does not employ structural engineers in-house. We coordinate with several Toronto-area firms based on project type, location, schedule, and homeowner preference:

BGE Engineering

• Strong residential foundation experience.
• Fast turnarounds on detached and semi-detached projects in the 416.
• Solid coverage across Toronto and East York district.
• Good fit for standard underpinning projects under 36 inches depth.
• Typical residential underpinning design fee: $4,500 to $7,500.

Glogowski Architectural

• Combines architectural and structural services in-house.
• Good fit when the project bundles underpinning with second-storey addition, major interior reconfiguration, or whole-house gut.
• Heritage-aware on Cabbagetown, Annex, Riverdale projects.
• Typical bundled fee for underpin plus addition: $9,500 to $18,000.

Cunningham Engineering

• Heritage masonry foundation expertise.
• Strong fit for Cabbagetown, Don Vale, parts of Riverdale, Annex projects with rubble masonry or older block walls.
• Careful, detail-heavy design — appropriate for buildings where the existing foundation needs respect.
• Typical residential underpinning design fee: $5,000 to $8,500.

Verner Polak Engineering

• Multiplex and multi-unit conversion experience.
• Frequently retained on Bill 23 multiplex projects where the underpinning is part of a four-plex or six-plex scope.
• Good coordination with City planning and zoning where unit-count changes are involved.
• Typical multiplex-scope fee: $8,000 to $15,000.

These four firms are not the only options in Toronto — there are dozens of qualified residential structural engineers. But these are the firms we have established working relationships with, and we can typically schedule a site visit within 2 weeks of project engagement.

How to Choose Between Firms

The criteria that drive firm selection on RenoHouse projects:

• 1. Project type: Standard underpin in standard housing — BGE. Heritage building — Cunningham. Bundled with addition — Glogowski. Multiplex scope — Verner Polak.
• 2. Schedule: All four firms are responsive but workload varies week to week. We check availability before recommending.
• 3. Homeowner preference: Some homeowners have an existing relationship with an engineer or have been recommended a firm. We work with the homeowner's choice as long as the firm is qualified and available.
• 4. Location: All four firms cover the entire Toronto area, but some have stronger ties to specific districts.
• 5. Fee transparency: We discuss fees upfront and confirm the scope is comparable across firms before recommending.

Homeowners can also choose to engage an engineer independently, before bringing in a contractor. We work with whatever PEng the homeowner has retained as long as the engineer is qualified and available for site visits.

What to Provide the Engineer

To produce a complete underpinning design, the engineer needs:

• Property survey (recent if available; older surveys often work).
• Existing basement layout with measurements at multiple points (corners, centre, near beams).
• Photographs of existing foundation walls (interior face), existing footing where visible, basement floor, mechanical room, and any visible water or settlement evidence.
• Existing house drawings if available (rare for pre-1970 construction; more common for newer builds).
• Soil report if completed; otherwise the engineer specifies one.
• Project scope document describing the planned use case, target ceiling height, and known constraints.
• Access for a site visit — typically 1 to 2 hours on site for measurements and observations.

A well-prepared package shortens engineering turnaround from 5 weeks to 3 weeks.

Engineer's Limits — What the Engineer Does Not Do

The PEng is responsible for the structural design. The engineer does NOT:

• Manage the project on site day-to-day. That is the contractor's role.
• Hire or schedule trades. Contractor's role.
• Take responsibility for contractor performance. The engineer signs off that the contractor's work meets the design — the contractor remains responsible for execution.
• Handle Building Permit submission directly. The engineer's drawings are part of the package, but the homeowner or contractor or architect submits.
• Coordinate asbestos abatement, electrical, plumbing, HVAC. These are separate trade scopes that the contractor manages.
• Provide finished basement design. Architectural drawings for the new layout, kitchen, bathroom, finishes are separate.

The engineer is the structural authority. The contractor is the project owner on the ground. The City is the regulator. The clean separation of roles is what makes the system function.

Engineer's Liability and Insurance

Professional Engineers in Ontario carry professional liability insurance (errors and omissions) as a condition of PEO licensure. Typical residential structural engineering firms carry $2 million to $5 million in E&O coverage. This is the homeowner's protection if the design itself proves deficient.

The contractor carries general liability insurance — typically $5 million for residential underpinning work — covering construction execution.

The two coverages overlap on some incidents and clarify on others. We require the engineer to provide proof of E&O coverage before engagement and we provide our general liability certificate to the homeowner.

What the Engineer Looks For During Site Visits

When the engineer conducts a site visit during construction, the focus areas:

• Pin width matches drawings. Wider pins are not safer — they exceed the design and may compromise the sequence.
• Pin depth matches drawings. Deeper than design can be acceptable; shallower is not.
• Adjacent pin spacing. No two adjacent pins open simultaneously.
• Cure time between sequences. 48 to 72 hours minimum, longer in cold weather.
• Concrete strength. Delivery tickets confirm 30 to 35 MPa as specified.
• Dowel placement. Dowels into the existing footing and emerging from the new pin to bond to the slab.
• Reinforcement. Rebar in the underpinning concrete where specified, properly placed and tied.
• Shoring. Where temporary support is specified, it is in place and in good condition.

The engineer's site visit notes become part of the project record and support the final compliance letter to the City.

Common Engineer-Contractor Friction Points

A few areas where engineer and contractor sometimes disagree, and how we handle them:

Pin width: contractor wants wider pins (faster work). Engineer specifies narrower. Resolution: follow the engineer. Cure time: contractor wants to move faster. Engineer specifies 72 hours. Resolution: follow the engineer. Shoring: contractor finds the engineer's shoring spec excessive for the conditions. Resolution: discuss before construction; if there is genuine disagreement, the engineer can revise based on observation but the contractor does not unilaterally reduce shoring. Surprise condition: contractor encounters unexpected wall condition. Resolution: stop, photograph, send to engineer, get revised drawing or written direction before proceeding.

The discipline that makes underpinning safe is exactly the discipline that prevents schedule heroics. We build in the time the engineer's design requires.

When to Engage the Engineer

The right time to engage the engineer is immediately after the project scope is defined and before any contractor quotes are finalized. Reasons:

• Engineer scope and fee are part of the budget.
• Engineer's method recommendation (full underpin, bench, hybrid) drives the contractor pricing.
• Engineer's depth and pin schedule drive the contractor schedule.
• Soil report timing depends on engineer's spec.

We typically engage the engineer in week 2 of a project — after initial site review and scope definition. The engineer's drawings are typically complete in week 6 to 8. Permit submission follows.
