# Electrical Panel Upgrade During Knob & Tube Rewiring Toronto

If you are rewiring K&T in your Toronto home, the question of whether to also replace the electrical panel comes up early in the quote conversation. The answer is almost always yes — and if your existing panel is a Federal Pioneer Stab-Lok, Wadsworth, Sylvania-Zinsco, or 60A fused panel, the answer is unequivocally yes regardless of K&T scope. This post explains why.

For the full rewiring guide, see [Knob & Tube Rewiring Toronto: Complete 2026 Guide](/blog/knob-tube-rewiring-toronto-2026-complete-guide).

Why Bundle the Panel Upgrade with K&T Rewiring

Three reasons the bundle is materially cheaper than two separate projects:

• 1. The LEC is already on site with the permit pulled. Permit fees, mobilization, and project management are not duplicated.
• 2. Drywall around the panel is already open for cable runs. Patching only happens once.
• 3. The new panel is sized for the rewired circuits. Doing the K&T first then the panel later means panel sizing has to be guessed at K&T scope.

Cost during the rewire: $2,500–$4,500 for a 100A or 200A panel upgrade. Cost as a standalone project later: $4,500–$7,000. The bundled cost is 30–40% lower.

Federal Pioneer Stab-Lok: The Mandatory Replace Case

Federal Pioneer (FP) Stab-Lok panels were widely installed in Canadian homes 1960–1980. The FP Stab-Lok design has a documented history of:

• Breakers failing to trip on overload — the breaker mechanism does not reliably interrupt fault current.
• Bus bar arcing — the stab connection between breaker and bus develops loose contact and arcs under load.
• Catastrophic failures — total panel fires originating from the panel itself, not from branch circuits.

Insurers in 2026 flag Stab-Lok panels independently of K&T. Many insurers refuse to bind coverage with a Stab-Lok panel even if all wiring is modern. The replacement is non-negotiable from an insurance and safety standpoint.

Visual identification: red and orange "Federal Pioneer" or "FPE" logo on the panel cover. Distinctive thin breakers (about half the width of modern Eaton or Schneider breakers). Often paired with K&T because the same era of installation.

Wadsworth and Sylvania-Zinsco: Same Story

Wadsworth panels (1950s–1970s) and Sylvania-Zinsco panels (1960s–1980s) have similar failure modes to Stab-Lok and are similarly flagged by insurers. Replacement during the rewire.

60A Fused Panels

Some pre-WWII Toronto homes still have 60A fused panels (no breakers, screw-in fuses). These panels are:

• Capacity-limited for modern loads.
• Usually undersized for 200A service required by EV chargers and heat pumps.
• A vintage that long predates modern grounding requirements.

Replacement is necessary to support modern household loads.

100A vs 200A: How to Decide

Once you commit to replacement, the next question is panel capacity. Three categories:

100A Panel: Adequate for Most 1,500–2,500 sq ft Homes

100A service is sufficient for:

• Standard household loads (appliances, lighting, HVAC).
• Gas furnace and gas water heater (low electrical demand).
• Single central air conditioner.
• Standard kitchen with electric range.

Cost: $2,500–$3,500 installed during a rewire.

200A Panel: Required for High-Load Homes

200A service is required for:

• Heat pump as primary HVAC (especially cold-climate models).
• Electric vehicle (EV) charging at Level 2 (40A circuit).
• Electric water heater plus electric range plus EV.
• Large home (3,000+ sq ft) with multiple HVAC zones.
• Future-proofing for electrification (heat pump, EV, induction range).

Cost: $3,500–$5,500 installed during a rewire, plus service mast and meter base if not already 200A-rated ($800–$2,000 add).

How to Choose

A simple load calculation determines whether 100A is enough or 200A is needed. A licensed electrician performs the calculation based on your appliance list and HVAC plans. The OESC requires the calculation be documented for any service upgrade.

In 2026, with electrification trends accelerating, RenoHouse generally recommends 200A for any rewire where:

• The homeowner intends to install a heat pump in the next 10 years.
• The homeowner intends to install EV charging.
• The home has 4+ bedrooms or 2,500+ sq ft.

The incremental cost from 100A to 200A during a rewire is modest ($1,000–$2,000) compared to retrofitting the upgrade later.

Brand Choice: Eaton, Schneider, Siemens

The three modern panel brands dominant in Toronto in 2026:

Eaton (CH Series)

• Long-running brand, broad parts availability.
• Bolt-on breakers (more secure than stab connections).
• Common in custom and high-end residential.
• Slightly higher cost than Schneider Homeline.

Schneider Square D (Homeline and QO Series)

• Homeline: builder-grade, plug-on breakers, good value.
• QO: premium, faster trip response, bolt-on, common in Schneider commercial.
• Both lines are widely supported in Toronto.

Siemens (Q-Line)

• Plug-on breakers, similar to Homeline tier.
• Long-running brand.
• Good parts availability.

All three are insurer-accepted. RenoHouse defers to the LEC partner's preference, which is usually based on parts inventory and breaker compatibility with their existing job stock. We do not specify a particular brand in our scope unless homeowner has a preference (e.g., to match existing if a sub-panel is being kept).

Service Mast and Meter Base

If the existing service is 60A or undersized 100A, the service mast (the conduit running from the meter to the weatherhead at the roof) and meter base may also need replacement. This is the most-coordinated portion of the project:

• Toronto Hydro disconnect required.
• Service mast and meter base replaced.
• Reconnect by Toronto Hydro.
• ESA service inspection same day.

Typical service work day: morning disconnect, electrical work 9 AM – 2 PM, reconnect 2–4 PM. Cost added: $1,500–$3,500.

EV-Readiness: Wiring for the Future

If the homeowner is considering EV charging in the next 5–10 years, two preparations during the rewire pay off:

• 40A or 50A circuit run from panel to garage or driveway (about $400–$800 added during a rewire vs $1,200–$2,500 retrofit).
• Panel space reserved for the EV breaker (no add cost during a rewire if 200A panel is being installed).

This is an "if you might do it eventually" decision worth making during the rewire to avoid retrofit costs.

Smart Panel Considerations

Some homeowners are considering smart panels (Span, Schneider Wiser, Eaton Energy Hub) that provide circuit-level monitoring, remote control, and load management. As of 2026:

• Smart panels add $2,000–$5,000 over conventional panels.
• They are excellent for EV/solar/battery management but unnecessary for typical residential use.
• ESA approval is required and adds inspection complexity.

For most Toronto K&T rewires, conventional panels (Eaton, Schneider, Siemens) are the right choice. Smart panels make sense for homes adding solar, battery storage, or multi-EV setups.

How RenoHouse Coordinates the Panel Upgrade

Through our ECRA/ESA-licensed electrical contractor partner:

• Pre-project load calculation to confirm 100A vs 200A.
• Toronto Hydro coordination for service disconnect/reconnect if service work in scope.
• Panel removal and replacement during a single-day window where possible.
• Circuit labeling completed at trim phase.
• ESA inspection as part of the K&T permit (no separate panel permit fee).

See the [Knob & Tube Rewiring Service Page](/services/electrical/knob-tube-rewiring).
